303-01D-91 Engine — 1.8L Diesel - Endura DE 303-01D-91
REMOVAL (CONTINUED)
E5886 EN 09/2001 2002 Bantam
35. Disconnect the plug of the reversing lamp
switch (where fitted).
36. Detach the shift rod and gearshift stabilizer
and tie up.
1. Shift rod
2. Shift rod stabilizer
37. Detach the rear exhaust pipe from the
flexible intermediate pipe.
• Remove the seal.
38. Disconnect the generator.
To Next Page
