303-01D-92 Engine — 1.8L Diesel - Endura DE 303-01D-92
REMOVAL (CONTINUED)
E5886 EN 09/2001 2002 Bantam
39. Detach the left and right-hand lower
suspension arms (left-hand side shown).
40. Disconnect the speedometer drive cable.
41. CAUTION: The inner joint must not
be bent at more than 18 degrees and
the outer joint must not be bent at
more than 45 degrees.
NOTE: Escaping oil. Close off the opening with
an auxiliary plug.
Press the left-hand front driveshaft out of
the transmission.
• Swing the driveshaft forward and tie it
up.
42. Remove the front driveshaft center bearing.
To Next Page
