303-01D-136 Engine — 1.8L Diesel - Endura DE 303-01D-136
ASSEMBLY (CONTINUED)
E6005 EN 09/2001 2002 Bantam
51. Fit the engine mounting bracket.
52. NOTE: Do not tighten the bolts.
NOTE: Center the slots on the injection pump
timing belt pulley.
Fit the injection pump timing belt pulley.
53. Fit the injection pump timing belt tensioner.
• Compress the spring of the timing belt
tensioner and lock it with the clamp bolt.
Engines with automatic timing belt tensioner.
54. Align the camshaft.
• Fit the timing tool into the groove in the
camshaft eccentric.
