303-01D-154 Engine — 1.8L Diesel - Endura DE 303-01D-154
INSTALLATION (CONTINUED)
E5915 EN 09/2001 2002 Bantam
All vehicles
24. CAUTION: The inner joint must not
be bent at more than 18 degrees and
the outer joint must not be bent at
more than 45 degrees.
Tighten the driveshaft center bearing.
25. CAUTION: The inner joint must not
be bent at more than 18 degrees and
the outer joint must not be bent at
more than 45 degrees.
CAUTION: When inserting the front axle
driveshafts always use the installation
sleeve (supplied with every new oil seal)
to protect the oil seal.
NOTE: Make sure the circlip engages correctly.
Install the left-hand driveshaft, together with
new retaining ring, in the transmission.
26. Top up the transmission fluid to 10 - 15 mm
below the lower edge of the filler/check
bore.
27. Attach the left and right-hand lower
suspension arm (left-hand side shown).
