204-01-8 Front Suspension 204-01-8
REMOVAL AND INSTALLATION (CONTINUED)
E1056 EN 06/2001 2002 Bantam
3.
CAUTION: The special tools must be
used to prevent damage to the hub. If
the hub is damaged a new hub must
be installed.
CAUTION: Do not use heat to remove the
bearing inner ring.
Using the special tools, remove the inner
race from the wheel hub.
4. Remove the circlip from the wheel knuckle.
5. Install the old bearing inner ring.
1. Install the bearing cage on to the
bearing.
2. Install the bearing cage and inner ring
assembly to the wheel knuckle.
6. Using the special tools, remove the bearing
outer ring from the wheel knuckle.
