308-03-63 Manual Transaxle 308-03-63
RE MOVAL (CONTINUED)
E6700 EN 07/2001
25. Remove the lower arm ball joints on both
sides (left-hand side shown).
26. Remove the constant velocity joint boot
clamp.
27. CAUTION: The inner joint must not
be bent at more than 18 degrees; the
outer joint must not be bent at more
than 45 degrees.
NOTE: Remove the grease filling.
Remove the halfshafts on both sides (left-
hand side shown, right-hand side similar).
Secure halfshafts with cable ties.
28. NOTE: The engine roll restrictor is under
tension.
Remove the engine roll restrictor.
29. Lower the vehicle.
