Revision History
MPC5604B Reference Manual Errata, Rev. 1
Freescale Semiconductor4
2 Revision History
Table 2 provides a revision history for this reference manual addendum document.
Chapter 25, Analog-to-Digital
Converter (ADC), page 610
In Section 25.4.6.2, Main Status Register (MSR), replace the ADCSTATUS field description with
the following:
The value of this parameter depends on ADC status:
000 IDLE — The ADC is powered up but idle.
001 Power-down — The ADC is powered down.
010 Wait state — The ADC is waiting for an external multiplexer. This occurs only when the
DSDR register is nonzero.
011 Reserved
100 Sample — The ADC is sampling the analog signal.
101 Reserved
110 Conversion — The ADC is converting the sampled signal.
111 Reserved
Chapter 26, Cross Triggering
Unit (CTU), page 633
At the end of Section 26.4.1, Event Configuration Registers (CTU_EVTCFGRx) (x = 0...63), add
the following Note:
NOTE
The CTU tracks issued conversion requests to the ADC. When the ADC
is being triggered by the CTU and there is a need to shut down the ADC,
the ADC must be allowed to complete conversions before being shut
down. This ensures that the CTU is notified of completion; if the ADC
is shut down while performing a CTU-triggered conversion, the CTU is
not notified and will not be able to trigger further conversions until the
device is reset.
Table 2. Revision History Table
Rev. Number Substantive Changes Date of Release
1.0 • Initial release. 05/2012
Table 1. MPC5604BCRM Rev 8 Addenda
Location Description
