MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 147
NOTE
Byte and half-word write accesses are not allowed for this register as a
predefined key is required to change its value.
8.3.1.3 Mode Enable Register (ME_ME)
Table 8-5. Mode Control Register (ME_MCTL) Field Descriptions
Field Description
TARGET_M
ODE
Target device mode — These bits provide the target device mode to be entered by software
programming. The mechanism to enter into any mode by software requires the write operation twice:
first time with key, and second time with inverted key. These bits are automatically updated by
hardware while entering SAFE on hardware request. Also, while exiting from the HALT and STOP
modes on hardware exit events, these are updated with the appropriate RUN0…3 mode value.
0000 RESET
0001 TEST
0010 SAFE
0011 DRUN
0100 RUN0
0101 RUN1
0110 RUN2
0111 RUN3
1000 HALT
1001 reserved
1010 STOP
1011 reserved
1100 reserved
1101 STANDBY
1110 reserved
1111 reserved
KEY Control key — These bits enable write access to this register. Any write access to the register
with a value different from the keys is ignored. Read access will always return inverted key.
KEY: 0101101011110000 (0x5AF0)
INVERTED KEY: 1010010100001111 (0xA50F)
Address 0xC3FD_C008 Access: Supervisor read/write
0123456789101112131415
R0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
00
STANDBY
00
STOP
0
HALT
RUN3
RUN2
RUN1
RUN0
DRUN
SAFE
TEST
RESET
W
Reset0000000000011101
Figure 8-4. Mode Enable Register (ME_ME)
