MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 149
8.3.1.4 Interrupt Status Register (ME_IS)
This register provides the current interrupt status.
Address 0xC3FD_C00C Access: Supervisor read/write
0123456789101112131415
R0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
000000000000
I_ICONF
I_IMODE
I_SAFE
I_MTC
W w1c w1c w1c w1c
Reset0000000000000000
Figure 8-5. Interrupt Status Register (ME_IS)
Table 8-7. Interrupt Status Register (ME_IS) Field Descriptions
Field Description
I_ICONF Invalid mode configuration interrupt — This bit is set whenever a write operation to ME_<mode>_MC
registers with invalid mode configuration is attempted. It is cleared by writing a ‘1’ to this bit.
0 No invalid mode configuration interrupt occurred
1 Invalid mode configuration interrupt is pending
I_IMODE Invalid mode interrupt — This bit is set whenever an invalid mode transition is requested. It is cleared
by writing a ‘1’ to this bit.
0 No invalid mode interrupt occurred
1 Invalid mode interrupt is pending
I_SAFE SAFE mode interrupt — This bit is set whenever the device enters SAFE mode on hardware requests
generated in the system. It is cleared by writing a ‘1’ to this bit.
0 No SAFE mode interrupt occurred
1 SAFE mode interrupt is pending
I_MTC Mode transition complete interrupt — This bit is set whenever the mode transition process completes
(S_MTRANS transits from 1 to 0). It is cleared by writing a ‘1’ to this bit. This mode transition interrupt
bit will not be set while entering low-power modes HALT, STOP, or STANDBY.
0 No mode transition complete interrupt occurred
1 Mode transition complete interrupt is pending
