MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 199
9.3.1.6 Destructive Event Alternate Request Register (RGM_DEAR)
This register defines an alternate request to be generated when a reset on a destructive event has been
disabled. The alternate request can be either a SAFE mode request to MC_ME or an interrupt request to
the system.
AR_CHKSTOP Alternate Request for checkstop reset
0 Generate a SAFE mode request on a checkstop reset event if the reset is disabled
1 Generate an interrupt request on a checkstop reset event if the reset is disabled
AR_SOFT Alternate Request for software reset
0 Generate a SAFE mode request on a software reset event if the reset is disabled
1 Generate an interrupt request on a software reset event if the reset is disabled
AR_CORE Alternate Request for debug control core reset
0 Generate a SAFE mode request on a debug control core reset event if the reset is disabled
1 Generate an interrupt request on a debug control core reset event if the reset is disabled
AR_JTAG Alternate Request for JTAG initiated reset
0 Generate a SAFE mode request on a JTAG initiated reset event if the reset is disabled
1 Generate an interrupt request on a JTAG initiated reset event if the reset is disabled
Address 0xC3FE_4012 Access: Read
0123456789101112131415
R
000000000000
AR_LVD27
AR_SWT
AR_LVD12_PD1
AR_LVD12_PD0
W
POR0000000000000000
Figure 9-7. Destructive Event Alternate Request Register (RGM_DEAR)
Table 9-8. Destructive Event Alternate Request Register (RGM_DEAR) Field Descriptions
Field Description
AR_LVD27 Alternate Request for 2.7 V low-voltage detected
0 Generate a SAFE mode request on a 2.7 V low-voltage detected event if the reset is disabled
1 Generate an interrupt request on a 2.7 V low-voltage detected event if the reset is disabled
AR_SWT Alternate Request for software watchdog timer
0 Generate a SAFE mode request on a software watchdog timer event if the reset is disabled
1 Generate an interrupt request on a software watchdog timer event if the reset is disabled
Table 9-7. Functional Event Alternate Request Register (RGM_FEAR) Field Descriptions (continued)
Field Description
