MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 403
21.7.1.16 Buffer data register MSB (BDRM)
DATA1 Data Byte 1
Data byte 1 of the data field.
DATA0 Data Byte 0
Data byte 0 of the data field.
Offset: 0x003C Access: User read/write
0123456789101112131415
R
DATA7 DATA6
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
DATA5 DATA4
W
Reset0000000000000000
Figure 21-21. Buffer data register MSB (BDRM)
Table 21-22. BDRM field descriptions
Field Description
DATA7 Data Byte 7
Data byte 7 of the data field.
DATA6 Data Byte 6
Data byte 6 of the data field.
DATA5 Data Byte 5
Data byte 5 of the data field.
DATA4 Data Byte 4
Data byte 4 of the data field.
Table 21-21. BDRL field descriptions (continued)
Field Description
