MPC5604B/C Microcontroller Reference Manual, Rev. 8
404 Freescale Semiconductor
21.7.1.17 Identifier filter enable register (IFER)
Offset: 0x0040 Access: User read/write
0123456789101112131415
R 0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R 00000000
FACT
W
Reset0000000000000000
Figure 21-22. Identifier filter enable register (IFER)
Table 21-23. IFER field descriptions
Field Description
FACT Filter activation (see Table 21-24)
0 Filters 2n and 2n + 1 are deactivated.
1 Filters 2n and 2n + 1 are activated.
This field can be set/cleared in Initialization mode only.
Table 21-24. IFER[FACT] configuration
Bit Value Result
FACT[0] 0 Filters 0 and 1 are deactivated.
1 Filters 0 and 1 are activated.
FACT[1] 0 Filters 2 and 3 are deactivated.
1 Filters 2 and 3 are activated.
FACT[2] 0 Filters 4 and 5 are deactivated.
1 Filters 4 and 5 are activated.
FACT[3] 0 Filters 6 and 7 are deactivated.
1 Filters 6 and 7 are activated.
FACT[4] 0 Filters 8 and 9 are deactivated.
1 Filters 8 and 9 are activated.
FACT[5] 0 Filters 10 and 11 are deactivated.
1 Filters 10 and 11 are activated.
FACT[6] 0 Filters 12 and 13 are deactivated.
1 Filters 12 and 13 are activated.
