MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 483
0110 7 1110 15
0111 8 1111 16
Table 23-8. DSPI PCS to SCK delay scaler
CSSCK PCS to SCK delay scaler value CSSCK PCS to SCK delay scaler value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
0110 128 1110 32768
0111 256 1111 65536
Table 23-9. DSPI After SCK delay scaler
ASC After SCK delay scaler value ASC After SCK delay scaler value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
0110 128 1110 32768
0111 256 1111 65536
Table 23-10. DSPI delay after transfer scaler
DT
Delay after transfer scaler
value
DT
Delay after transfer scaler
value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
Table 23-7. DSPI transfer frame size (continued)
FMSZ Frame size FMSZ Frame size
