24.5.4.4 Current Timer Value Register (CVAL)
This register indicates the current timer position.
24.5.4.5 Timer Control Register (TCTRL)
This register contains the control bits for each timer.
Table 24-26. LDVAL field descriptions
Field Description
TSV Time Start Value
This field sets the timer start value. The timer counts down until it reaches 0, then it generates an interrupt
and loads this register value again. Writing a new value to this register does not restart the timer, instead
the value is loaded once the timer expires. To abort the current cycle and start a timer period with the new
value, the timer must be disabled and enabled again (see Figure 24-63).
Offset: channel_base + 0x04 Access: Read
0123456789101112131415
RTVL[31:16]
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R TVL[15:0]
W
Reset0000000000000000
Figure 24-59. Current Timer Value Register (CVAL)
Table 24-27. CVAL field descriptions
Field Description
TVL Current Timer Value
This field represents the current timer value. Note that the timer uses a downcounter.
Note: The timer values will be frozen in Debug mode if the FRZ bit is set in the PIT Module Control
Register (see Figure 24-2).
