MPC5604B/C Microcontroller Reference Manual, Rev. 8
650 Freescale Semiconductor
Offset: 0x0000 Access: Read/write
0123456789101112131415
R
EDC0000 SIZE 0 LAS 000MAS
W
w1c
Reset
0000001000100000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
EER RWE 0 0
PEAS
DONE
PEG 0 0 0 0
PGM
PSUS
ERS
ESUS
EHV
W
w1c w1c
Reset
0000011000000000
Figure 27-3. CFlash Module Configuration Register (CFLASH_MCR)
Table 27-9. CFLASH_MCR field descriptions
Field Description
EDC Ecc Data Correction
EDC provides information on previous reads. If an ECC Single Error detection and correction
occurred, the EDC bit is set to ‘1’. This bit must then be cleared, or a reset must occur before
this bit will return to a 0 state. This bit may not be set to ‘1’ by the user.
In the event of an ECC Double Error detection, this bit will not be set.
If EDC is not set, or remains 0, this indicates that all previous reads (from the last reset, or
clearing of EDC) were not corrected through ECC.
0: Reads are occurring normally.
1: An ECC Single Error occurred and was corrected during a previous read.
SIZE array space SIZE
The value of SIZE field is dependent upon the size of the flash memory module; see
Table 27-10.
LAS Low Address Space
The value of the LAS field corresponds to the configuration of the Low Address Space; see
Table 27-11.
MAS Mid Address Space
The value of the MAS field corresponds to the configuration of the Mid Address Space; see
Table 27-12.
EER Ecc event ERror
EER provides information on previous reads. If an ECC Double Error detection occurred, the
EER bit is set to ‘1’.
This bit must then be cleared, or a reset must occur before this bit will return to a 0 state.
This bit may not be set to ‘1’ by the user.
In the event of an ECC Single Error detection and correction, this bit will not be set.
If EER is not set, or remains 0, this indicates that all previous reads (from the last reset, or
clearing of EER) were correct.
0: Reads are occurring normally.
1: An ECC Double Error occurred during a previous read.
