Table 27-64 shows the relationship of haddr[25:24] to the number of additional wait-states. These are
applied in addition to those specified by haddr[28:26] and thus extend the total wait-state specification
capability.
Table 27-63. Additional wait-state encoding
Memory address
haddr[28:26]
Additional wait-states
000 0
001 1
010 2
011 3
100 4
101 5
110 6
111 7
Table 27-64. Extended additional wait-state encoding
Memory address
haddr[25:24]
Additional wait-states
(added to those specified by haddr[28:26])
00 0
01 8
10 16
11 24
