170 Upgrade and Maintenance Manual RX2540 M2
Hard disk drives (HDD) and solid state drives (SSD)
7.3.2 Upgrading SAS/SATA HDD backplane 2
7.3.2.1 Preliminary steps
Ê "Locating the defective server" on page 61
Ê "Suspending BitLocker functionality" on page 95
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
7.3.2.2 Installing the 3.5-inch HDD backplane 2
Ê "Installing the 4x 3.5-inch HDD SAS backplane 2" on page 167
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: flat screw driver
Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
