Fujitsu PRIMERGY RX2540 M2

RX2540 M2 Upgrade and Maintenance Manual 241
Expansion cards and backup units
* Slot 4, 5,10 and 11 are only available with a riser card.
** Slot 3 and 9 are PCIe slots and usable for slot expansion with riser cards (two
types).
I The list may be changed due to new controllers.
For the latest information of the installing order, refer to your server’s
hardware configurator available online at the following address:
for the global market:
http://ts.fujitsu.com/products/standard_servers/index.htm
for the Japanese market:
http://jp.fujitsu.com/platform/server/primergy/system/
8.1.1 Riser modules
There are two types of riser modules available:
– A short riser card holder with a PCIe riser card with 2x PCIe Gen3 x8 slots
– A long riser card holder with a PCIe riser card with 1x PCIe Gen3 x16 slot
PCI
slot
Type CPU Type length Function
1 PCIe Gen 3 1 x8 (mech.x8)
half length
(HL)
only low profile (LP)
2 PCIe Gen 3 1 x8 (mech.x16) HL only LP
3** PCIe Gen 3 1 x16 (mech.x16) HL only LP, riser slot
4* PCIe Gen 3 1
x16 (mech.x16) full length (FL) full heigth (FH), with D3264
x8 (mech.x8) FL FH, with D3274
5* PCIe Gen 3 1 x8 (mech.x8) FL
FH, only available with riser
D3274
6 not available
7 PCIe Gen 3 2 x8 (mech.x8) HL only LP
8 PCIe Gen 3 2 x16 (mech.x16) HL only LP
9** PCIe Gen 3 2 x16 (mech.x16) HL only LP, riser slot
10* PCIe Gen 3 2
x16 (mech.x16) FL full height (FH), with D3264
x8 (mech.x8) FL FH, with D3274
11* PCIe Gen 3 2 x8 (mech.x8) FL
FH, only available with riser
D3274
