RX2540 M2 Upgrade and Maintenance Manual 425
12.3.2.4 Concluding steps
Ê "Installing the front panel cage" on page 485
Ê "Installing the fan box" on page 399
Ê "Reassembling" on page 73
Ê "Connecting the power cord" on page 79
Ê "Resuming BitLocker functionality" on page 120
12.3.3 Replacing an optical disc drive (ODD)
12.3.3.1 Preliminary steps
Ê Ask the system administrator to eject all remaining backup or optical media
from the backup or ODD before removing it from the server.
Ê "Suspending BitLocker functionality" on page 95
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
Ê "Removing the front panel cage" on page 479
12.3.3.2 Removing the defective ODD
Ê "Removing the ODD" on page 422
12.3.3.3 Installing the new ODD
Ê "Installing an ODD" on page 417
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
