218 Upgrade and Maintenance Manual RX2540 M2
Hard disk drives (HDD) and solid state drives (SSD)
Ê Connect the cables to the second/third backplane as described in section
"Connecting cables to backplane 2/3" on page 208.
Ê If applicable, install the SAS expander board as described in section
"Installing the SAS expander board" on page 220.
Ê If applicable, install the SAS expander holder as described in section
"Installing the SAS expander holder" on page 221.
7.5.5.3 Concluding steps
Ê "Installing the fan box" on page 399
Ê "Reassembling" on page 73
Ê "Installing 2.5-inch HDD/SSD modules" on page 193
Ê "Connecting the power cord" on page 79
Ê "Switching on the server" on page 82
Ê "Resuming BitLocker functionality" on page 120
7.5.6 Replacing the SAS expander board
7.5.6.1 Preliminary steps
Ê "Locating the defective server" on page 61
Ê "Suspending BitLocker functionality" on page 95
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
