RX2540 M2 Upgrade and Maintenance Manual 201
Hard disk drives (HDD) and solid state drives (SSD)
I For further information, please refer to the "ServerView Suite RAID
Management" user guide and manuals of RAID controller.
7.4.4.2 Removing a 2.5-inch HDD/SSD module
Ê "Removing a 2.5-inch HDD/SSD module" on page 198
7.4.4.3 Installing a 2.5-inch HDD/SSD module
Ê "Installing 2.5-inch HDD/SSD modules" on page 193
7.4.4.4 Concluding steps
Ê "Performing a RAID array rebuild" on page 121
7.5 Replacing 2.5-inch HDD/SSD SAS/SATA
backplanes
7.5.1 Replacing the 8x 2.5-inch HDD/SSD SAS
backplane 1
7.5.1.1 Preliminary steps
Ê "Locating the defective server" on page 61
Ê "Suspending BitLocker functionality" on page 95
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: flat screw driver
Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
