210 Upgrade and Maintenance Manual RX2540 M2
Hard disk drives (HDD) and solid state drives (SSD)
Ê If applicable, connect the two SAS cables to the backplane 3, see figure 110
on page 209:
– Cable T26139-Y4040-V32 to backplane connector X10 (1)
– Cable T26139-Y4040-V31 to backplane connector X9 (2)
Ê Connect power cables to the backplane:
– Power cable to (3)
– If applicable, ODD power cable (4)
– If applicable OOB cable (5)
I For a complete cabling overview, please refer to section "List of used
cables" on page 559.
7.5.2.6 Concluding steps
Ê If applicable, "Installing the SAS expander holder" on page 221
Ê "Installing the fan box" on page 399
Ê "Reassembling" on page 73
Ê "Installing 2.5-inch HDD/SSD modules" on page 193
Ê "Connecting the power cord" on page 79
Ê "Switching on the server" on page 82
Ê "Resuming BitLocker functionality" on page 120
7.5.3 Upgrading the 4x 2.5-inch PCIe SSD backplane
(front side)
7.5.3.1 Preliminary steps
Ê "Locating the defective server" on page 61
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less
