RX2540 M2 Upgrade and Maintenance Manual 529
System board and components
Figure 401: Securing the TPM
Ê Connect the new TPM to the system board (1).
Ê Secure the TPM with the TPM screw using the TPM bit insert (2).
I Do not fasten the screw too firmly. Stop as soon as the head of the
screw lightly touches the TPM.
14.4.1.3 Concluding steps
Ê "Reassembling" on page 73
Ê "Connecting the power cord" on page 79
Ê Enable TPM in the system board BIOS. Proceed as follows:
Ê Switch on or restart your server.
Ê As soon as the startup screen appears, press the [F2] function key to
enter the BIOS.
Ê Select the Advanced menu.
Ê Select the Trusted Computing submenu.
Ê Set the TPM Support and TPM State settings to Enabled.
Ê Under Pending TPM operation, select the desired TPM operation mode.
