420 Upgrade and Maintenance Manual RX2540 M2
Ê Push the ODD latch upward, so that ODD latch is engaged firmly (2).
Figure 304: Installing the front panel module (A)
Ê Connect the ODD power cable (C5).
Ê Connect the ODD SATA cable (C3).
12.3.1.4 Concluding steps
Ê "Installing the front panel cage" on page 485
Ê "Installing the fan box" on page 399
Ê "Reassembling" on page 73
Ê "Connecting the power cord" on page 79
Ê "Resuming BitLocker functionality" on page 120
