RX2540 M2 Upgrade and Maintenance Manual 503
Front panel and external front connectors
13.8.3 Replacing the front USB3.0 connector
13.8.3.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 95
Ê "Locating the defective server" on page 61
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
13.8.3.2 Removing the front panel module
Ê "Removing the front panel cage" on page 479
13.8.3.3 Removing the front USB3.0 connector
Ê "Removing the front USB3.0 connector" on page 502.
13.8.3.4 Installing the new front USB3.0 connector
Ê Install the new front USB3.0 connector as described in section "Installing the
front USB3.0 connector" on page 498.
13.8.3.5 Installing the front panel module
Ê "Installing the front panel module" on page 483.
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
