472 Upgrade and Maintenance Manual RX2540 M2
Front panel and external front connectors
13.3.3.4 Installing the new front VGA connector
Ê Install the new front VGA connector as described in section "Installing the
front VGA" on page 468.
13.3.3.5 Installing the front panel module
Ê "Installing the front panel module" on page 458.
13.3.3.6 Concluding steps
Ê "Installing the fan box" on page 399
Ê "Reassembling" on page 73
Ê "Connecting the power cord" on page 79
Ê "Switching on the server" on page 82
Ê "Resuming BitLocker functionality" on page 120
13.4 Front USB3.0 connector 3.5-inch versions
13.4.1 Installing the front USB3.0 connector
13.4.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 95
Ê "Locating the defective server" on page 61
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
