Fujitsu PRIMERGY RX2540 M2

402 Upgrade and Maintenance Manual RX2540 M2
Accessible drives
12.1 Basic informations
Mounting order for accessible drives in the front panel cage
PRIMERGY RX2540 M2 server offers
– one 5.25-inch accessible drive bays for ODDs
– one bay (optional) for a LTO drive or a RDX drive
I LTO drive or RDX drive are not available for 3.5-inch HDD versions.
Figure 282: Accessible drive in front panel module 3.5-inch HDD version
Figure 283: Accessible drives in front panel module 2.5-inch HDD version
1 ODD 2 RDX drive
LTO drive
