Fujitsu PRIMERGY RX2540 M2

RX2540 M2 Upgrade and Maintenance Manual 571
Cables
15.2.2.4 Configuration 4x 2.5-inch PCIe SSD rear
Figure 427: Cabling - 4x 2.5-inch PCIe SSD rear option
15.2.2.5 Configuration 4x 2.5-inch SAS HDD/SSD rear
Figure 428: Cabling - 4x 2.5-inch SAS HDD/SSD rear option
PWR 12V 4
SB D3289
PCIe slot 8
I2C5
P0 / X1
PCIe SSD BP
4 x 2.5" rear
P1 / X2
P2 / X3
P3 / X4
X11 (OOB)
X12 (PWR)
C33
D 3262 P CIe ctrl.
P0 / X1
P1 / X2
P2 / X3
P3 / X4
cable bundle with
colour marking
C2 8
C27
SB
BP4
BP 1 - 3
C27PWR 12V 4
SB D3289
PCIe slot 7
I2C5
SAS 3.0
controller
FBU
C29
FBU
C16
C33
SB
BP4
BP 1 - 3
SAS/ SATA HDD/
SSD
BP 4 x 2.5" rear
X5 (SAS HD)
X11 (OOB)
X1 0 ( P W R )
MLC1
MLC2
