180 Upgrade and Maintenance Manual RX2540 M2
Hard disk drives (HDD) and solid state drives (SSD)
Ê Insert all HDD/SSD modules, see section "Installing 3.5-inch HDD modules"
on page 147.
I Make sure that you reinstall the HDD/SSD module in the bay it was
located before the HDD backplane replacement.
Ê "Connecting the power cord" on page 79
Ê "Switching on the server" on page 82
Ê "Resuming BitLocker functionality" on page 120
7.3.4 Replacing the SAS expander board
7.3.4.1 Preliminary steps
Ê "Locating the defective server" on page 61
Ê "Suspending BitLocker functionality" on page 95
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
7.3.4.2 Removing the SAS expander holder
Ê Remove the SAS expander holder as described in section "Removing the
SAS expander board" on page 174.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
