336 Upgrade and Maintenance Manual RX2540 M2
Expansion cards and backup units
8.8.3 Removing the DynamicLoM module
8.8.3.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 96
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê If a riser module 1 is installed, remove the riser module 1 refer to "Removing
the riser module 1 (HL)" on page 84.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tool: – Phillips PH1/ (+) No. 1 screw driver
– Phillips PH2/ (+) No. 2 screw driver
– nut driver 5 mm
