348 Upgrade and Maintenance Manual RX2540 M2
9.1 Basic information
Figure 244: Memory overview
– The system board is equipped with 24 memory slots
(12 connectors per CPU).
– In 1 CPU configurations only 12 memory slots are usable.
– The system has to be equipped with at least one memory module per CPU.
– Supported capacities: 2 GB, 4 GB, 8 GB,16 GB, 32 GB or 64 GB
– Maximum amount of RAM: 1536 GB (768 GB per CPU)
– Supported memory modules:
DIMM 1E
DIMM 3H
DIMM 2H
DIMM 1A
DIMM 1G
DIMM 3F
DIMM 2F
DIMM 1F
DIMM 3E
DIMM 2E
DIMM 3D
DIMM 3C
DIMM 2D
DIMM 1H
DIMM 2G
DIMM 3G
DIMM 2A
DIMM 1B
DIMM 3A
DIMM 3B
DIMM 2B
DIMM 1C
DIMM 1D
DIMM 2C
