RX2540 M2 Upgrade and Maintenance Manual 193
Hard disk drives (HDD) and solid state drives (SSD)
7.4.2 Installing 2.5-inch HDD/SSD modules
7.4.2.1 Preliminary steps
Ê Locate the correct drive bay as described in section "2.5-inch HDD/SSD
configurations" on page 187.
Position Logical drive
number
ServerView RAID Manager display name
(Enclosure number: Port number)
one SAS controller
[1] 0 Vendor Product (1:0)
[2] 1 Vendor Product (1:1)
[3] 2 Vendor Product (1:2)
[4] 3 Vendor Product (1:3)
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
