Accessible drives
Figure 330: Connecting the cables to the RDX drive (D)
Ê Route the USB cable as shown (see arrows).
12.5.1.4 Concluding steps
Ê "Installing the fan box" on page 399
Ê "Reassembling" on page 73
Ê "Connecting the power cord" on page 79
Ê "Resuming BitLocker functionality" on page 120
12.5.2 Removing the RDX drive
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
