Expansion cards and backup units
8.1 Basic information
The system board is equipped with seven expansion slots:
Figure 141: PCI slot overview on the system board
Figure 142: PCI slot overview on the rear
Slot 9
Riser 2
Slot 8
Slot 7
DynLoM
Slot 3
Slot 2
Slot 1
Riser 1
Slot 11
Slot 10
Slot 9 Slot 8 Slot 7
Slot 5
Slot 4
Slot 3 Slot 2 Slot 1
