RX2540 M2 Upgrade and Maintenance Manual 543
System board and components
14.6.2 Removing the iRMC microSD card
14.6.2.1 Preliminary steps
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
14.6.2.2 Removing the iRMC microSD card
Figure 411: Removing the iRMC microSD card
Ê To eject the iRMC microSD card, gently push it in and then let go (1).
Ê Pull the iRMC microSD card straight out of its slot (2).
V CAUTION!
The iRMC microSD card contains customer information. After removing
the iRMC microSD card, hand the card over to the customer.
14.6.2.3 Concluding steps
Ê "Reassembling" on page 73
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
