586 Upgrade and Maintenance Manual RX2540 M2
HDD prefailure detection
Depending on your hardware configuration HDD prefailure detection will be
supported.
The requirements are:
– iRMC Firmware 7.14 or later
– supported OOB RAID system
– RAID controllers, which are not listed in the table below
16.3.2 Server front
16.3.2.1 Indicators on the front panel
Figure 443: Indicators on the front panel
RAID controllers that do not support HDD prefailure detection
D2616/MegaRAID SAS 9280-8e MegaRAID SAS9285CV-8e
D3116/D3116C D2607
Table 6: RAID controllers that do not support HDD prefailure detection
