Indicator Status Description
A Identification
blue on
server has been highlighted using the ID
button on the front panel for easy
identification
blue
flashing
server has been highlighted using IRMC
(AVR) when local VGA off for easy
identification
B
CSS
(Customer Self
Service)
off no critical event (CSS component)
yellow on prefailure detected (CSS component)
yellow
flashing
CSS component failure
C
GEL
(Global Error
LED)
off no critical event (non CSS component)
orange on
prefailure detected (non CSS
component)
orange
flashing
non CSS component failure
Possible reasons:
– sensor reports overheating
– sensor is defective
–CPU error
– software reports an error
F Controller orange on Controller faulty
G CPU orange on CPU faulty
H Memory orange on Memory faulty
I MBC PWR OK green on Power supply ok
K MBC ERROR orange on Power supply error
L Main power green on PWROK
M Standby power yellow on PWROK STBY
N iRMC
green
flashing
iRMC S4 ok
O Fan orange on Fan faulty
P Battery orange on Battery faulty
