304 Upgrade and Maintenance Manual RX2540 M2
Expansion cards and backup units
I Therefore an already installed RAID controller must be removed, see
"Removing an expansion card" on page 258 and "Installing an
expansion card" on page 256.
8.6.3.11 Installing the air duct riser module 2
Figure 200: Preparing the air duct for riser module 2
Ê Break out the blind cover on the left side from the air duct using a side cutter
(see circles).
Figure 201: Installing the air duct
Ê Insert the air duct.
