RX2540 M2 Upgrade and Maintenance Manual 269
Expansion cards and backup units
8.5.2 Removing an expansion card from riser module 1
8.5.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 95
Ê "Shutting down the server" on page 65
Ê Remove all external cables from the expansion card to be removed.
I If there is a cable installed to an expansion card in the upper slot, see
section "Note for installation with expansion cards in slot 5 and slot
11" on page 83.
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê If applicable, disconnect internal cables from the expansion cards.
Ê If applicable, "Removing an SFP+ transceiver module" on page 252.
Ê Remove the riser module 1 as described in section "Removing the riser
module 1 (HL)" on page 84
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver / nut driver 5 mm
