RX2540 M2 Upgrade and Maintenance Manual 207
Hard disk drives (HDD) and solid state drives (SSD)
Ê "Installing the fan box" on page 399
Ê "Reassembling" on page 73
Ê "Installing 2.5-inch HDD/SSD modules" on page 193
Ê "Connecting the power cord" on page 79
Ê "Switching on the server" on page 82
Ê "Resuming BitLocker functionality" on page 120
7.5.2 Replacing the 8x 2.5-inch HDD/SSD SAS
backplane 2/3
7.5.2.1 Preliminary steps
Ê "Locating the defective server" on page 61
Ê "Suspending BitLocker functionality" on page 95
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê Remove all HDD/SSD modules from the server as described in section
"Removing 2.5-inch HDD/SSD modules" on page 197.
V CAUTION!
Ensure that all HDDs are uniquely identified so that you can reinsert
them into their original bays after replacing the HDD backplane.
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
Ê If applicable, "Removing the SAS expander holder" on page 219.
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: flat screw driver
Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
