Front panel and external front connectors
13.7.2.4 Installing the front panel module
Ê "Installing the front panel module" on page 483
13.7.2.5 Concluding steps
Ê "Installing the fan box" on page 399
Ê "Reassembling" on page 73
Ê "Connecting the power cord" on page 79
Ê "Switching on the server" on page 82
Ê "Resuming BitLocker functionality" on page 120
13.7.3 Replacing the front VGA connector
13.7.3.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 95
Ê "Locating the defective server" on page 61
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
13.7.3.2 Removing the front panel module
Ê "Removing the front panel cage" on page 479
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PH1 / (+) No. 1screw driver
Phillips PZ2 / (+) No. 2 screw driver / nut driver 5 mm
