450 Upgrade and Maintenance Manual RX2540 M2
Ê Fasten the air grid with 4 screws.
Ê "Installing the front panel cage" on page 485
12.5.2.3 Concluding steps
Ê "Installing the fan box" on page 399
Ê "Reassembling" on page 73
Ê "Connecting the power cord" on page 79
Ê "Resuming BitLocker functionality" on page 120
12.5.3 Replacing a RDX drive
12.5.3.1 Preliminary steps
Ê Ask the system administrator to eject all remaining backup or optical media
from the backup or ODD before removing it from the server.
Ê "Suspending BitLocker functionality" on page 95
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
Ê "Removing the front panel cage" on page 479
12.5.3.2 Removing the defective RDX drive
Ê "Removing the RDX drive" on page 447
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
