Front panel and external front connectors
13.7.2.3 Removing the front VGA cable
Figure 371: Mounting the front VGA connector
Ê Remove the two screws of the front VGA card.
Ê Remove the front VGA card.
Figure 372: Installing the front VGA cover plate
Ê Insert the front VGA cover plate from the front until it snaps in place (see
circle).
