RX2540 M2 Upgrade and Maintenance Manual 383
10.5 Handling CPU heat sinks
10.5.1 Preliminary steps
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
10.5.2 Installing CPU heat sinks
Figure 266: Standard CPU heat sink V26898-B1001-V1
Field Replaceable Unit
(FRU)
if thermal paste is involved
Hardware: 15 minutes
Upgrade and Repair Unit
(URU)
Tool: Phillips PH2 / (+) No. 2 screw driver
