RX2540 M2 Upgrade and Maintenance Manual 395
11.2 Replacing the system fan
11.2.1 Preliminary steps
Ê "Locating the defective server" on page 61
Ê "Getting access to the component" on page 68
Ê "Locating the defective component" on page 63
11.2.2 Removing a system fan
Figure 276: Removing a system fan
Ê Take the system fan by the two handles (1).
Ê Lift the system fan out of the fan box (2).
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
