358 Upgrade and Maintenance Manual RX2540 M2
9.3 Removing memory modules
9.3.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 95
Ê "Disabling SVOM boot watchdog functionality" on page 96
Ê "Locating the defective server" on page 61
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
9.3.2 Removing a memory module
Ê Identify the desired memory slot see section "Memory sequence" on
page 349.
V CAUTION!
Ensure to maintain an operational configuration when removing
memory modules. For additional information, please refer to section
"Basic information" on page 348.
Figure 247: Removing memory modules (A)
Ê Eject the desired memory module by pressing out the securing clips at each
end of the memory slot.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
