464 Upgrade and Maintenance Manual RX2540 M2
Front panel and external front connectors
Ê "Locating the defective server" on page 61
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
13.2.1.2 Removing the front panel module
Ê "Removing the front panel module" on page 455
13.2.1.3 Removing the front panel board
Figure 343: Removing the front panel board
Ê Disengage the four noses.
Ê Remove the front panel board.
