RX2540 M2 Upgrade and Maintenance Manual 559
15 Cables
This chapter provides information on how to connect, disconnect and route
cables.
Safety notes
V CAUTION!
● Always hold cables by their connectors when disconnecting them.
Never pull on the cable to disconnect cables.
● Ensure that none of the cables are scraped, strained or otherwise
damaged while replacing system components.
● Immediately replace cables with damaged shielding.
● Always use shielded network cables.
15.1 List of used cables
No Name Cable number Routing
C1
CBL FRONT
PANEL GTL
T26139-Y4015-V301
Front panel board to
system board
C2
CBL_USB30_65
0
T26139-Y3999-V505
Front USB3.0 to system
board
C3
LTG SATA
CBL_SATA_850
T26139-Y4028-V304 ODD to system board
C4
CBL_FRONT_V
GA
T26139-Y3994-V301 Front VGA to system board
C5 CBL PWR 2CO
400
T26139-Y3986-V302 ODD to SAS BP 1
C6
CBL PWR SAS-
BP 660
T26139-Y3939-V503 SAS BP 1 to system board
C8 CBL SAS3.0A500 T26139-Y4040-V26
SAS controller to expander
board
Table 5: List of used cables
