Accessible drives
12.2.1.3 Installing an ODD
Figure 285: Installing the ODD
Ê Remove the two screws (see circles).
Ê Remove the cover plate of the front panel module.
Ê Turn the cover plate of the front panel module upside down.
Figure 286: Noses in the cover plate of the front panel module
