RX2540 M2 Upgrade and Maintenance Manual 535
System board and components
14.4.3.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 95
Ê "Locating the defective server" on page 61
Ê "Shutting down the server" on page 65
Ê "Disconnecting the power cord" on page 66
Ê "Getting access to the component" on page 68
Ê "Removing the fan box" on page 397
14.4.3.2 Removing the TPM
Ê "Removing the TPM" on page 530
Ê Leave the TPM spacer on the system board when removing the defective
TPM.
14.4.3.3 Installing the TPM
Figure 404: TPM spacer
Ê The TPM spacer is already present on the system board.
Ê "Installing the TPM" on page 526
